Specifications
| Voltage | AC220V 50/60HZ |
| Power | 1500W |
| Syringe Outer Diameter | Φ8-20mm（Can be customized） |
| Label Length | 20~60mm |
| Label Height | ≤80mm |
| Capacity | 0~70b/min（Depending on object size and label length） |
| Roll Outer Dia | Φ300mm |
| Roll Inner Dia | Φ76mm |
| Label Gap | ≥3mm |
| Dimension | 1200*1000*1800mm |
| Weight | 400KG |
Performance
Syringe Labeling Machine automatically applies labels to designated positions on the syringe; simultaneously, it prints batch numbers, production dates, and output counts. In case of bottle shortages, the control system prevents label delivery, effectively preventing label waste. The labeling speed can be infinitely adjusted according to the production characteristics of each factory, ensuring the machine can be used independently or in conjunction with other machines. The labeling pressing component ensures satisfactory labeling results even on bottles with uneven surfaces.
Key Features
Automatic Labeling: This machine can automatically apply labels to syringes at the designated positions with high precision.
Batch Printing: It integrates the ability to print batch numbers, production dates, and production counts, ensuring complete labeling and tracking.
No Label Waste: The system is equipped with sensors to detect missing syringes, preventing label wastage when no syringe is present.
Adjustable Labeling Speed: The machine allows for stepless speed adjustment based on factory requirements, ensuring versatility whether used independently or integrated into a production line.
Smooth Labeling Effect: The label application system ensures clean and smooth label adhesion even on irregular surfaces.
High-End Configuration
| HMI | Siemens | Germany |
| PLC | Siemens | Germany |
| Labeling Servo Motor | Panasonic | Japan |
| Motor Driver | Panasonic | Japan |
| Sensors | SICK | Germany |
| Sensors | Lion | USA |
| Pneumatic Components | AirTAC | Taiwan |
| Star Disc Motor | ChaoGang | Taiwan |
| Star Disc Gearbox | JiaCheng | China |
| Labeling System Integration | RICIO | China |
Benefits of the Star Disc Syringe Labeling Machine
High-Speed Labeling: Capable of labeling up to 70 syringes per minute, optimizing production efficiency.
Precision Labeling: Accurate and consistent label application, even on small or irregular surfaces.
Flexible Labeling Range: Supports a wide range of syringe sizes and label dimensions, from 20mm to 60mm in length.
Durable and Reliable: Manufactured using high-quality components, ensuring long-term durability and reliability in high-demand environments.
Simple Operation and Maintenance: User-friendly HMI interface for easy operation and quick maintenance.
Customizable Settings: The labeling speed, distance, and application settings can be adjusted for different production needs.
Low Maintenance Cost: Designed to minimize downtime and reduce maintenance costs, keeping your operation running smoothly.
Efficient and Accurate: The star disc mechanism ensures uniform and smooth label application, preventing label misalignment or waste.
Mid-Range Configuration
| HMI | Delta | Taiwan |
| PLC | Delta | Taiwan |
| Servo Motor | RuiNeng | China |
| Motor Driver | RuiNeng | China |
| Sensors | SICK | Germany |
| Sensors | Lion | USA |
| Pneumatic Components | AirTAC | Taiwan |
| Star Disc Motor | ChaoGang | Taiwan |
| Gearbox and Labeling Motor | Leadshine | China |
| Labeling System Integration | RICIO | China |
Applications
This machine is designed for labeling small cylindrical products such as syringes, tubes, and other similar items across a range of industries. It is highly suitable for use in packaging lines for products that require high-speed and high-precision labeling.
Optional functions and components
1、 Code printer: the hot printer can print the date of production, expiration date, batch number, etc. Marking and labeling are synchronized to improve production efficiency.
2、 Inkjet printer: it can match the mainstream inkjet printer in the market, spray code at the designated position of the label, and perfectly combine with the labeling machine.
3、 Universal sensor: ordinary sensor can not detect transparent label, so it must be used with special electric eye imported from Germany.
4、 Reader: read two-dimensional code, bar code and other information, easy to establish product database for product traceability.
