Carton Corner Labeling Machine RXL-C type CTN can automatically affix the label to the specified position; meanwhile, it can complete the printing of batch number, production date, output counting, corner folding, etc. The machine can be used alone or inline with other machines according to the production characteristics of each factory. In the event of lack of material, the control system to ensure that the label is not sent, effectively preventing the waste of labels, and according to the production characteristics of each factory for stepless speed regulation of the labeling speed, so as to ensure that the machine can be used individually or in line with other machines to use the labeling components to make the surface of the bottle is not too flat to get a satisfactory labeling effect.

Corner Labeling Machine RXL-C type can be adapted to various specifications, colors, materials of the box, so the machine is widely used in medicine, food, light industry, beverage, daily chemicals and other industries.

Box Corner Labelling Machine Tech. Parameters

Corner Tamper Label Machine Functions & Characteristics

1. dedicated to box corner labeling, to achieve the box on the plane and side plane corner labeling, play a role in preventing tampering;
2. high speed, poker corner labeling speed of 180 boxes / minute, greatly improving production efficiency;
3. labeling is firm, do not fall off. Labeling on the plane part, the roller roller pressure overlay labeling stick fast, side plane part, brush stroking stick fast;
4. labeling beautiful, set the top mechanism, box conveyor high stability, labeling, labeling effect;
5. Intelligent control, automatic photoelectric tracking, with nothing not labeling, no labeling automatic correction and labeling automatic detection function, to prevent leakage and labeling waste;
6. high stability, Siemens PLC(SIEMENS) touch screen + (KEYENCE) needle-shaped electric eye + German Lloyd Labeling electric eye composed of high-level electronic control system to support the equipment 7*24 hours operation.

Labeling Machine Corner Sealing Work Process

Core working principle: the sensor detects the product passing by, sends back the signal to the labeling control system, at the appropriate position the control system controls the motor to send out the label and attach it to the product to be labeled position, the product flows through the labeling brushes, the label is brushed over and the labeling action of a label is completed.

Operation process:
(1)-> put the product (connected to the assembly line)
(2)-> product conveying
(3)-> product inspection
(4)-> double-side labeling
(5)-> brush labeling
(6)-> collection of labeled products (into the next section of the assembly line).

Corner Label Labeling Machine Spare Parts List

Labeling-machine-corner-sealing Basic Purpose

It’s esp. for the box corner sealing labeling machine , in the box on the plan and side plan corner sealing labeling, play the role of anti-tampering. Mainly used in poker, electronic products, mask box and drug box tamper-evident labeling double side labeling.

Automatic corner labeling machine can be matched with plane labeling machine to form continuous labeling.

Corner 90 Degree Labeling Machine Applications Range

1. Applicable labels: self-adhesive labels, self-adhesive film, electronic regulatory code, bar code, etc.
2. Applicable products: all kinds of cartons, such as poker boxes, cell phone boxes, etc.
3. Applicable industries: widely used in printing, food, daily chemicals, electronics, medicine and other industries.
4. Applicable examples: the Nestle box tamper-evident labeling, poker CTN tamper-evident labeling, network card box tamper-evident labeling, mask box, etc.
